How to handle the error measures in precision parts processing

Reasonable error is a normal phenomenon in the processing of precision parts. No matter how precise processing measures are taken by the parts processing factory, normal errors cannot be avoided. In the testing report, as long as there is a reasonable error, it is qualified. A significant error is definitely unqualified. What measures are generally taken to avoid it?

1. Local errors in precision parts processing

Many automated parts processing factories often encounter reasonable dimensional errors in the processed workpiece during product error detection, but local dimensional errors are significant. In fact, this reason is mainly caused by the large gap between the screw mother and the screw in the lathe.

Originally, there were gaps in this area, but after a long period of operation of the lathe, the gap between the screw and the screw will naturally widen. When programming precision parts processing, the compensation error of this gap was considered, but the newly added gap was not compensated, resulting in local dimensions exceeding the tolerance. Usually, it is necessary to repair this gap or replace the lead screw.

2. Overall error in precision parts processing

If the overall error of the processed workpiece is large, it is basically necessary to redo it. Loose connections between the lathe and the screw or screw can easily cause significant errors. When machining a workpiece, the cutting resistance is very high. If the connection becomes loose, there will be size drift during cutting. The connection of this lathe must be tightened in order to eliminate the error fault.

Another situation is that the looseness of the electric tool holder can also cause significant errors in the machined parts. During the tool change process, the tool holder cannot automatically lock, and the lower tool point will shift during cutting, which inevitably leads to significant errors. It is necessary to lock the tool holder to avoid this error.
