What safety issues should be paid attention to during the 5-axis CNC machining process

Safety issues to pay attention to during the 5-axis CNC machining process



1. Five axis CNC machining should try to install the clamping material first and then the clamping tool to prevent hands from touching the tool during the clamping material. If the cutting tools have already been installed, when loading materials, the workbench should first be moved to the outside to ensure that there is no interference with the cutting tools during loading materials, so as to avoid injury or breaking the cutting tools.
​
2. When disassembling the tool, it is important to first observe whether the spindle stops rotating.



3. When unloading the knife, do not forcefully grip or pinch the edge of the knife to avoid scratching the blade.



4. The wrench should be placed in the tool storage area after use, and it is not allowed to be placed on the Y-axis shield or crossbeam.



5. During the 5-axis CNC machining process, operators are not allowed to observe the cutting position closely to prevent chips from falling into the eyes.



6. Before starting the five axis CNC machining, check the position of the oil nozzle before turning on the oil pump switch to avoid spraying oil into other positions during flushing.



7. When pausing to observe the gap in the five axis CNC machining, it is necessary to move the workbench away from the cutting position.



8. After the completion of processing and before disassembling the workpiece, we first need to conduct necessary preliminary dimensions or appearance inspections. Only after passing the inspection can the workpiece be disassembled, in order to avoid positioning problems in secondary processing and causing workpiece scrapping after disassembly. The disassembled workpiece requires further testing of some key dimensional data to ultimately meet the processing requirements.
